Chapter 9: TCP & UDP

Overview

This chapter explores TCP (Transmission Control Protocol) and UDP (User Datagram Protocol), the two primary transport-layer protocols used in network programming. Understanding their differences, behavior, and appropriate use cases is essential for building reliable and efficient networked applications.

Key topics covered in this chapter include:

• Introduction to TCP and UDP
• Protocol features and differences
• Socket programming with TCP vs. UDP
• Packet structure and communication flow
• When to use TCP or UDP
• Examples in C and common debugging tools

Introduction to TCP and UDP

TCP and UDP are protocols used for sending data over networks. They sit above the IP layer in the protocol stack and differ primarily in how they handle reliability, ordering, and connection management.

TCP: Transmission Control Protocol

TCP is a connection-oriented, reliable, and stream-based protocol. It ensures data is delivered in order and without duplication.

Key TCP Features:

• Connection establishment (3-way handshake)
• Reliable delivery with acknowledgments
• Flow and congestion control
• Ordered byte stream

TCP Communication Flow:

1. Client calls connect() to initiate communication.
2. Server calls listen() and accept() to establish the connection.
3. Data is exchanged using send() and recv().
4. The connection is closed using close().

UDP: User Datagram Protocol

UDP is a connectionless, unreliable, and message-based protocol. It is suitable for applications where speed is critical and some data loss is acceptable.

Key UDP Features:

• No connection setup
• No guarantee of delivery or order
• Low overhead and latency
• Messages (datagrams) are sent as discrete packets

UDP Communication Flow:

1. No connection is established.
2. Data is sent with sendto() and received with recvfrom().

TCP vs. UDP Comparison

Feature	TCP	UDP
Connection	Yes	No
Reliable	Yes	No
Ordered	Yes	No
Flow Control	Yes	No
Overhead	High	Low
Use Cases	Web, FTP, Email	DNS, Video Streaming, VoIP

TCP Example in C

// TCP Server
int server_fd = socket(AF_INET, SOCK_STREAM, 0);
bind(server_fd, ...);
listen(server_fd, 5);
int client_fd = accept(server_fd, NULL, NULL);
send(client_fd, "TCP Hello", 9, 0);
close(client_fd);

UDP Example in C

// UDP Server
int sockfd = socket(AF_INET, SOCK_DGRAM, 0);
bind(sockfd, ...);
char buffer[1024];
recvfrom(sockfd, buffer, sizeof(buffer), 0, ...);
sendto(sockfd, "UDP Hello", 9, 0, ...);

Choosing Between TCP and UDP

Application Type	Recommended Protocol
File transfer, web services	TCP
Real-time video/audio, gaming	UDP
Remote shell, email	TCP
DNS queries, SNMP	UDP

Considerations:

• Use TCP when reliability and order are critical.
• Use UDP when speed matters more than reliability.

Debugging and Testing Tools

• netstat: View active TCP/UDP connections
• tcpdump / wireshark: Packet-level analysis
• nc (netcat): Test TCP/UDP connections
• nmap: Scan for open ports and services

Interactive Quiz

1. Which protocol guarantees ordered delivery of data?

   A. UDP
   B. TCP
   C. ICMP


   Show Answer

   The correct answer is B. TCP provides reliable and ordered delivery.

2. Which function is typically used to send a UDP message in C?

   A. connect()
   B. sendto()
   C. write()


   Show Answer

   The correct answer is B. UDP uses sendto() and recvfrom().

3. Which protocol would be best for live video streaming?

   A. TCP
   B. UDP
   C. FTP


   Show Answer

   The correct answer is B. UDP is often used for real-time streaming where speed is prioritized over reliability.

Summary

• TCP is reliable, connection-oriented, and suited for data integrity.
• UDP is fast, connectionless, and suited for real-time applications.
• The choice between TCP and UDP depends on application needs.
• Tools like netstat, tcpdump, and nc help analyze network behavior.

In the next chapter, we’ll dive into Threads, a concurrency mechanism that enables parallel execution within a process.

---

This chapter is based on material from "Advanced Programming in the UNIX Environment, Third Edition, by W. Richard Stevens and Stephen A. Rago, 2013."
